AC110-220V Input Voltage P4.28 Round LED Display 1/14 Scan Mode Customized Design
Product Details:
| Place of Origin: | shenzhen,China |
| Brand Name: | H&S LED |
| Certification: | CE ROHS FCC |
| Model Number: | P4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Packaging Details: | Fight case/Wooden case/Honeycomb Box |
| Delivery Time: | 10-45 workdays |
| Payment Terms: | L/C, T/T, D/A, T/T, Western Union, MoneyGram |
| Supply Ability: | 300-1000Set |
|
Detail Information |
|||
| Produce Name: | LED Circle Display | Module: | P4 |
|---|---|---|---|
| Produce Size: | Die600mm | Pixel Composition: | 1R1G1BLED (SMD1921) |
| Brightness: | 5500CD | Scan Mode: | 1/14 Scan |
| Refresh Rate: | 3840HZ | Input Voltage: | AC110-220V |
| Cabinet Material: | Die-casting Aluminum | ||
| Highlight: | P4.28 Round LED Display,Customized Design Round LED Display |
||
Product Description
| PH4.28 Technical Specifications | |||||||
| Pixel point parameter | |||||||
| 1 | LED | SMD1921 | |||||
| 2 | Pixel Pitch | 4.28mm | |||||
| 3 | Pixel composition | 1R1G1B | |||||
| Module technical parameters | |||||||
| 1 | Module resolution (W * H) | 70*70dot | |||||
| 2 | Module size (W * H) | 300mm*300mm | |||||
| Screen body technical parameters | |||||||
| 1 | Full screen size | 640mm*640mm*120mm | |||||
| 2 | dot density | 54289dot/m² | |||||
| 3 | screen resolution | One side 140*140 points,Double-sided 280*140 points | |||||
| 4 | Brightness (white field color temperature 6500K) | 5500cd/m² | |||||
| 5 | Horizontal view/vertical view | 140°/140° | |||||
| 6 | Best visual distance (m) | 4-100m | |||||
| 7 | flatness | ≥99% | |||||
| 8 | Chroma uniformity | ±0.003 Cx,Cy之内 | |||||
| 9 | service life | >100,000 Hours Theoretical value | |||||
| 10 | way to install | Side hanging, Mosaic, wall hanging, lifting | |||||
| 11 | Protection Class | IP65 | |||||
| 12 | weight | Single side ≈12KG double side ≈16KG | |||||
| System control parameter | |||||||
| 1 | Signal color processing bits | Red, green, and blue ≥14bit | |||||
| 2 | type of drive | Constant current drive 1/14 scan | |||||
| 3 | repetition frequency | 60 frames per second | |||||
| 4 | refresh rate | ≥3840HZ/S | |||||
| 5 | maximum power | Single side 200W/ set, double side 400W/ set | |||||
| 6 | average power | Single side 67W/ set, double side 134W/ set | |||||
| 7 | Operating Temperature Range | -40°C~+60°C | |||||
| 8 | Screen color temperature | 2000K-9500K is adjustable | |||||
| 9 | brilliance control | Manual/automatic/program control | |||||
| 10 | control mode | Asynchronous control/mobile APP, WIFI, U disk, cloud platform | |||||
application:
-
Advertising and Brand Promotion: These screens stand out in crowded urban landscapes, attracting attention with vibrant visuals and dynamic content. Businesses can use them to showcase their products, services, and promotions, creating an engaging and memorable advertising experience for passersby.
-
Event and Entertainment Venues: At concerts, sports stadiums, festivals, and other large-scale events, circular LED screens add to the spectacle by displaying live feeds, scores, replays, and event-related information. They enhance audience engagement and create an immersive viewing experience.
-
Public Information Displays: Municipalities and government agencies can utilize outdoor circular LED screens to disseminate critical information such as weather updates, emergency alerts, public announcements, and traffic conditions. Their circular design often allows for better visibility from multiple angles, making them ideal for community information hubs.
-
Retail and Mall Atriums: In shopping malls and retail outlets, these screens can be used to feature promotions, new arrivals, and store directories. They contribute to an ambiance of modernity and excitement, encouraging customer footfall and interaction.
-
Art Installations and Public Art: Artists and designers often employ circular LED screens as mediums for creative expressions, blending art with technology to present unique visual narratives. These installations can elevate public spaces, fostering cultural appreciation and dialogue.
-
Transportation Hubs: Airports, train stations, and bus terminals benefit from circular LED screens for displaying flight schedules, train times, arrival and departure information, and travel advisories. Their clarity and versatility ensure that travelers stay informed amidst bustling environments.
-
Corporate and Campus Signage: Companies and educational institutions can install these screens on their campuses to welcome visitors, display news, achievements, and upcoming events. They serve as dynamic and professional communication tools that reflect the organization's culture and values.
